Specification

Length

Length

Length

Length

Length

Casement Width

Arm Width

Max.Door/
Window Height

Max.Door/
Window Width

Max.Door/
Window Weight

Supportive Suspension Strip Thickness

Height

Opening
Angle

8"

205

30

126

46

109

18

16

1000

350

7.3

2.0±0.2

15±0.5

60°±2°

10"

255

30

185

37

137

18

16

1200

450

9.7

2.0±0.2

15±0.5

90°±2°

12"

295

30

202

60

150

20

16

1200

600

11.8

2.0±0.2

15±0.5

90°±2°

14"

340

30

253

55

183

20

16

1000

350

16.2

3.0±0.2

16.5±0.5

90°±2°

16"

400

30

281

86

198

20

16

1500

500

19.6

3.0±0.2

16.5±0.5

90°±2°

18"

450

30

190

225

189

20

16

1500

600

23.5

3.0±0.2

15±0.5

90°±2°
